Expandable Homes › 儿童游乐设备

秋千

享受户外休闲时光的完美选择。这款秋千设计简洁耐用，适合全家使用。坚固的框架结构确保安全稳定，舒适的座椅让您放松身心。无论是在花园、公园还是院子里，都能为您和家人带来欢乐和放松。安装简便，维护容易，是打造温馨户外空间的理想伴侣。

1–6Bedrooms

Layout dependentBathroom

Up to 61.9m²Expanded

9Layout Options

Indicative pricing $5,000.00 Final price depends on layout, specification, freight and site requirements.

View reference layout Start Your Project

◉ Actual Product

How It Expands

Folded
Compact and secure for transport.

Delivered
Delivered to your site, ready to go.

Positioned
Set in place and secured.

Expanded
Walls slide out and lock.

Connected
Utilities connected. Your home is ready.

Reference layout

View all layouts →

Original configuration drawing

30FT · 1 Bedroom

Configure Your Home

SPC Flooring

Selected: Standard

Kitchen Cabinetry

Selected: Standard

Cabinet Colour

Selected: Standard

Exterior Colour

Selected: Standard

From Factory to Home

Folded
Compact and secure for transport.

Delivered
Delivered to your site, ready to go.

Positioned
Set in place and secured.

Expanded
Walls slide out and lock.

Connected
Utilities connected. Your home is ready.

Handover
Final checks and project completion.

●Level ground & clear access

●Concrete piers or slab ready

●Water & power connection points

●Site access for delivery truck

Built to Last. Backed with Confidence.

10Year Structural

5Year Construction

1Year Fit-Out

Frequently Asked Questions

How long does installation take?

Timing depends on site access and approvals. Our team provides a project-specific schedule.

Do I need council approval?

Approval requirements differ by location and intended use. We can help you identify the relevant pathway.

Can I customise the layout?

Yes. Available layouts, finishes and included options can be configured for each series.

What areas do you deliver to?

Delivery coverage and costs depend on your site location and access conditions.

Ready to make it yours?

Save your configuration and let our team help you take the next step.

Submit This Configuration Request Project Review

CONFIGURATION REFERENCE · 2026

30FT specifications & drawings

Review the current supplier configuration and original reference drawings.

Flat roof

Transport size · L × W × H: 9000 × 2200 × 2456 mm
Expanded size · L × W × H: 9000 × 6880 × 2560 mm

Sloped roof

Transport size · L × W × H: 9000 × 2200 × 2480 mm
Expanded size · L × W × H: 9000 × 6300 × 2480 mm

Insulation conductivity (supplier)0.048 W/(m·K)

Sound insulation (supplier)≥30 dB

Wind load (supplier)0.60 kN/m²

Floor live load (supplier)2.0 kN/m²

Structure, materials & services

Specification	Flat roof	Sloped roof
Main floor & roof beams	80 × 100 × 2.5 mm galvanised steel sections.	80 × 100 × 2.5 mm galvanised steel sections.
Floor secondary members	80 × 40 × 2.0 mm galvanised rectangular tubes.	60 × 40 × 1.5 mm galvanised rectangular tubes.
Roof secondary members	40 × 40 × 1.2 mm galvanised tubes.	40 × 40 × 1.5 mm and 20 × 40 × 1.5 mm galvanised tubes.
Columns	80 × 100 mm galvanised sections, 2.5 mm material thickness.	210 × 150 mm galvanised sections, 2.5 mm material thickness.
Expandable wing frame	P80 × 1.5 mm special tube; 3.0 mm L-shaped galvanised plate; 50 × 100, 80 × 100, 80 × 40 and 50 × 30 mm rectangular tubes with 2.0 mm walls; L30 × 30 × 1.2 mm angle.	P80/P65 × 1.5 mm special tubes; 2.0 mm L-shaped galvanised plate; 40 × 80 × 1.5 mm rectangular tube; L30 × 30 × 1.0 mm angle.
Roof & ceiling	V980 profiled waterproof roof sheet, 0.45 mm thick; EPS composite insulation panels with 0.3 mm steel skins and 12 kg/m³ core. Final 50/100 mm panel build-up to be confirmed.	50 mm EPS composite roof panel with V195 profiled ceiling. Roof skin thickness requires confirmation because the reference lists two values.
External walls	75 mm EPS composite panels, 950 mm module width, 0.3 mm coated steel skins and 12 kg/m³ core. The metal-clad option is listed with a 50 mm panel; confirm the selected build-up.	75 mm EPS composite panels, 950 mm module width, 0.3 mm coated steel skins and 12 kg/m³ core; white-grey smooth finish.
Structural floor	18 mm asbestos-free cement board to the centre floor; 18 mm magnesium-oxide board to the expandable wings.	18 mm cement board to the centre floor; 18 mm plywood to the expandable wings.
Floor finish	2.0 mm PVC floor covering.	2.0 mm PVC floor covering.
Entry & internal doors	1220 × 2258 mm thermally broken aluminium double entry door; 55-series profile; blue-tinted 5 + 12 + 5 double glazing.	Thermally broken aluminium double entry door, at least 1900 × 2280 mm, with toughened glass; 780 × 2050 mm steel internal doors.
Windows	uPVC sliding windows: six 930 × 930 mm units and one 750 × 550 mm unit in the listed base configuration; clear 5 + 6 + 4 double glazing. Quantities and positions require layout confirmation.	930 × 930 mm uPVC sliding windows.
Lighting & distribution	15 W LED ceiling lights; four single-key switches; surface-mounted distribution box with one leakage-protection device and three circuit breakers. Listed base socket mix: ten five-hole and three three-hole outlets; destination specification to be confirmed.	15 W LED ceiling lights; 12 W bathroom light; concealed distribution box. Switch and socket specification to be confirmed for the destination.
Power connection & wiring	One 220 V / 50 Hz / 3P32A industrial connection. Cable schedules: incoming 3 × 6 mm²; air conditioning 3 × 4 mm²; outlets 3 × 2.5 mm²; lighting 2 × 1.5 mm². These are supplier reference values, not an Australian electrical approval.	One 220 V / 50 Hz / 3P32A industrial connection. Cable schedules: incoming 3 × 6 mm²; air conditioning 3 × 4 mm²; outlets 3 × 2.5 mm²; lighting 2 × 1.5 mm². These are supplier reference values, not an Australian electrical approval.
Seals & drainage	D-profile seals at moving joints, butyl waterproof tape and organised roof drainage.	D-profile seals at moving joints, butyl waterproof tape and organised roof drainage.
Frame finish	Electrostatic powder-coated finish. Coating thickness unit requires supplier confirmation.	Electrostatic powder-coated finish. Coating thickness unit requires supplier confirmation.
